• Model NO.：outdoor p6
• Pixel Density：27777DOT,M2
• Scanning Mode：1,4 Scan
• Display Type：LED Video Display
• Application：Advertising
• Certification：CE, RoHS, UL, CCC, SGS ISO
• Waterproof：IP65
• Viewing Angle Vertical/Horizontal：140 Degree
• Module Size：384*192mm,192*192mm
• Warranty Time：3~5 Years
• Programmable Card：Linsn,Xixun,Colorlight,Nova,Listen
• Good Colors：1r1g1b
• Delivery Time：3-12orking Days
• Support Input Signal：HDTV CATV NTSC PAL S-Video VGA VCD DVD
• Interface：Network,Erial Port,50 Chip,Parallel RS 232,Solar P
• Diode Model：Silan,Nichia,CREE,Epistar,Opto
• Transport Package：Anti-Shaking Wooden; Air Flight Case; Carton Case
• Specification：CE; ROHS; SGS. ETC. SGS; ISO
• Trademark：FOXGOLDEN
• Origin：Shenzhen
• HS Code：8528591090
• Production Capacity：4000sqm,Month

Basic Info.

Model NO. outdoor p6 Pixel Density 27777DOT/M2 Scanning Mode 1/4 Scan Display Type LED Video Display Application Advertising Certification CE, RoHS, UL, CCC, SGS ISO Waterproof IP65 Viewing Angle Vertical/Horizontal 140 Degree Module Size 384*192mm/192*192mm Warranty Time 3~5 Years Programmable Card Linsn/Xixun/Colorlight/Nova/Listen Good Colors 1r1g1b Delivery Time 3-12orking Days Support Input Signal HDTV CATV NTSC PAL S-Video VGA VCD DVD Interface Network/Erial Port/50 Chip/Parallel RS 232/Solar P Diode Model Silan/Nichia/CREE/Epistar/Opto Transport Package Anti-Shaking Wooden; Air Flight Case; Carton Case Specification CE; ROHS; SGS. ETC. SGS; ISO Trademark FOXGOLDEN Origin Shenzhen HS Code 8528591090 Production Capacity 4000sqm/Month

Product Description

 P6 outdoor full color led display


Numbers	Technical indexes	Specification
1	Pixel Pitch	6mm
2	Density of Pixel	27777dots/M2
3	Pixel configuration	RGB
4	Size of Single Board	192mm *192mm or 384*384mm
5	Colors	16777216
6	Best Viewing Distance	6-250M
7	Horizontal Viewing Angle	140°
8	Maximum Power Consumption	1100W/m2
9	Brightness	8000cd/m2
10	Gray Scale	14 bits per color
11	Color Temperature	6500k
12	Control Method	synchronization & Asynchronization
13	Driving method	constant scanning
14	Frame Frequency	60Hz
15	Refresh frequency	≤2800Hz
16	Working Voltage	AC220V/110±10%
17	IP grade	IP65
18	Working temperature	-35centigrade - +80 centigrade
19	Computer operation system	Win 98/  Win XP/  Win 2000/winme/win7
20	Brightness adjustment	256 grade manual, 8 grade automatic
21	Video signal	RF, S-Video, RGB, RGBHV, YUV, YC.ect
22	Software	LED play software
23	MTBF	More than 10000 hours
24	Life Span	100,000 hours

Company overview
Foxgolden Group Ltd is one of the most impressing Hi-tech enterprises in China. Since 2004, we have been dedicating to the aim that making high  quality products, and have been well integrated with R & D, production, project, capital and marketing.
As a professional and market-oriented LED display manufacturer ,FOXGOLDEN not only keeps improving on normal LED display screen, enhances the product's cost-effective and overall market competitiveness , but also makes breakthrough progresses on special usgaes. Our products, with high quality and competitive prices, spread worldwide and earn excellent public reputation from both domestic and oveerseas market.
FOXGOLDEN provides a full series of LED display products involving various single and dual color , text & image display; indoor single & dual color , full color screen; outdoor single & dual color , full color display; dot matrix module display; traffic applied product;and series of indoor & outdoor module
With cultivation for high-quality production management team and project team , high quality products and local maintenance service; we only achieved 0.001% complaint in product quality for 7 constant years. that's why Foxgolden has received comprehensive attention form LED industrial experts these yea

 Welcome to Foxgolden........


Foxgolden Group Ltd
Address:  No.57,Shuitian Fourth Industrial Park,Shiyan Town,Baoan District,Shenzhen City,China

Foxgolden had been engaged in designing and manufacturing LED display for more than 11 years. Our products have certificates like CE/FCC/RoHS/NQA /SGS/ISO.
The best quality products and excellent service will be provided to you by our professional team.
