High Brightness Outdoor LED Video Advertisng Display with Pixel 4.81mm

PRT Optoelectronic Co., Ltd.
  • Tube Chip Color：Full Color
  • IP Rating：IP65
  • Pixel Pitch：4.81mm
  • Pixel Configuration：1R, 1G, 1B
  • Display Function：Video Display
  • Average Power Consumption：300W , m²

Base Info

  • Model NO.：P4.81
  • Pixel Density：43264dots,Sq.M
  • Scanning Mode：1,13 Scan
  • Display Type：LED Video Display
  • Application：Stage Performance, Advertising,Rental
  • Certification：CE, RoHS, ETL
  • Type of LEDs：SMD2727
  • Panel Size：500X500mm,500X1000mm
  • Panel Resolution：104X104 Dots,104,208dots
  • Module Size：250X250mm
  • Transport Package：Flight Case
  • Specification：CE, ROHS, FCC, ETL
  • Trademark：PRT
  • Origin：Shenzhen China
  • HS Code：8528591090
  • Production Capacity：3000sq. M,Month

Description

P4.81 Outdoor full Color LED Screen SpecificationPixel pitch4.81mmPixel Configuration1R1G1BLED componentSMD2727 Size of module250mm x 250mmResolution of module52x52Size of cabinet500x500mm/500mm x 1000mm x 75mmResolution of cabinet104x104/104x208Material of CabinetDie-casting AluminumWeight of Cabinet8kgs/14KGSBrightness>5500cd/sq.mDensity43264dots/sq.mBest viewing angle160 /140Pixel Configuration1R1G1BBest viewing distance3-60MMaximum power consumption800W/sq.mAverage power consumption300W/sq.mDriving method1/13 scanControl methodSynchronizationGray scale65536Colors256*256*256Color temperature3200-9300kUniformity97%Working voltageAC220V/110V±10%Working temperature-20ºC~+50ºC±10%Working humidity10% ~ 90%MTBF10,000 hoursFrame frequence50/60HzRefresh frequence>2000HzIP gradeIP65Life Span100,000 hoursData transafer methodRJ45Pratical standardCCC  TUV-CE  ETL etc.Effectivce Communication
Distance(without relay)Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M;
Single-mode optic fiber: 10KMAccepting signal with video processorPAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc.Systems operating platformWINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development
