• Model NO.：P6
• Pixel Density：27777dots,Sq.M
• Scanning Mode：1,8 Scan
• Display Type：LED Video Display
• Application：Advertising, Stage Performance, Rental
• Certification：CE, RoHS, CCC
• LED Encapsulation：SMD3535
• Module Size：192X192mm
• Module Resolution：32X32dots
• Cabinet Size：Customized
• Transport Package：Wooden Case or as Required
• Specification：CE, FCC. ROHS, 3C
• Trademark：PRT
• Origin：Shenzhen China
• HS Code：8528591090
• Production Capacity：3000sq. M,Month

P6 SMD3535 Outdoor full Color LED Screen SpecificationPixel pitch6mmPixel Configuration1R1G1BLED componentSMD3535Size of module192mm x 192mmResolution of module 32 x32dotsSize of cabinet960mm x 960mm x 150mm /768x768mm or customizedResolution of cabinet160x160dots /128x128dotsMaterial of CabinetIron/AluminumWeight of Cabinet45KGS/28kgsBrightness>6000cd/sq.mDensity27777dots/sq.mBest viewing angle140 /140Pixel Configuration1R1G1BBest viewing distance5-60MMaximum power consumption1000W/sq.mAverage power consumption560W/sq.mDriving method1/8 scanControl methodSynchronizationGray scale65536Colors256*256*256Color temperature3200-9300kUniformity97%Working voltageAC220V/110V±10%Working temperature-20ºC~+50ºC±10%Working humidity10% ~ 90%MTBF10,000 hoursFrame frequence50/60HzRefresh frequence>1920HzIP gradeIP65/IP54Life Span100,000 hoursData transafer methodRJ45Pratical standardCCC  TUV-CE  ETL etc.Effectivce Communication
Distance(without relay)Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M;
Single-mode optic fiber: 10KMAccepting signal with video processorPAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc.Systems operating platformWINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development
