High Brightness Outdoor Waterproof P4 LED Display Screen for Advertising
PRT Optoelectronic Co., Ltd.- Tube Chip Color:Full Color
- IP Rating:IP65
- Pixel Pitch:4mm
- Pixel Configuration:1R, 1G, 1B
- Display Function:Video Display
- Average Power Consumption:600W , m²
Base Info
- Model NO.:P4
- Pixel Density:62500dots,Sq.M
- Scanning Mode:1,8 Scan
- Display Type:LED Video Display
- Application:Advertising,Stage, Performance, Rental
- Certification:CE, RoHS, CCC, FCC
- Cabinet Size:512X512mm
- Cabinet Material:Iron,Aluminum
- Module Size:256X128mm
- Module Resolution:64X32dots
- Transport Package:Flight Case or Wooden Case
- Specification:CE, FCC. ROHS, 3C
- Trademark:PRT
- Origin:Shenzhen
- HS Code:8528591090
- Production Capacity:3000sq. M,Month
Description
Pixel pitch4mm Pixel Configuration 1R1G1B LED component SMD1921 Size of module 256mm x 128mm Resolution of module 64x32dots Size of cabinet 512mm x 512mm / 512mm x 768mm x 150mm Resolution of cabinet 128x128dots/128x192dots Material of Cabinet Iron or Aluminum Weight of Cabinet 15KGS Brightness >6000cd/sq.m Density 62500dots/sq.m Best viewing angle 140° /140° Pixel Configuration 1R1G1B Best viewing distance 3-50M Maximum power consumption 1000W/sq.m Average power consumption 600W/sq.m Driving method 1/8 scan Control method Synchronization Gray scale 65536 Colors 256*256*256 Color temperature 3200-9300k Uniformity 97% Working voltage AC220V/110V±10% Working temperature -20ºC~+50ºC±10% Working humidity 10% ~ 90% MTBF 10,000 hours Frame frequence 50/60Hz Refresh frequence >1920Hz IP grade IP65 Life Span 100,000 hours Data transafer method RJ45 Pratical standard CCC TUV-CE ETL etc. Effectivce Communication
Distance(without relay) Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M;
Single-mode optic fiber: 10KM Accepting signal with video processor PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc. Systems operating platform WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development
Distance(without relay)
Single-mode optic fiber: 10KM
