Outdoor P10 Digital Advertising HD Advertising LED Video Panel
Shenzhen Hongking Optoelectronic Co., Ltd.- Tube Chip Color：Full Color
- IP Rating：IP67
- Pixel Pitch：10mm
- Pixel Configuration：1r1g1b, SMD 3535
- Display Function：Video Display, Image & Text Display, Text Display, Market Display
- Average Power Consumption：220W , m²
Base Info
- Model NO.：Outdoor LED Display P10-2S
- Pixel Density：10000dots,M2
- Scanning Mode：1,2 Scan
- Display Type：LED Video Display
- Application：Stage Performance
- Certification：CE, RoHS, CCC
- Product Name：Outdoor LED Display P10-2s(SMD)
- Driver IC：Mbi5124
- Bightness CD/Sqm：7000CD,M2
- Grey Scale：65536 Degree
- Life Time：More 100, 000 Hours (80%)
- Mtbf：More 50, 000 Hours
- Operating Temperature：-30~-60t
- Humidity：10%-95%
- Color Temperature：6500-9500K
- Transport Package：The Factory Packaging
- Specification：320*160mm
- Trademark：hongking
- Origin：China
- HS Code：8528591090
- Production Capacity：5000 Sqm,Year
Description
Basic Info.
Model NO. Outdoor LED Display P10-2S Pixel Density 10000dots/M2 Scanning Mode 1/2 Scan Display Type LED Video Display Application Stage Performance Certification CE, RoHS, CCC Product Name Outdoor LED Display P10-2s(SMD) Driver IC Mbi5124 Bightness CD/Sqm 7000CD/M2 Grey Scale 65536 Degree Life Time More 100, 000 Hours (80%) Mtbf More 50, 000 Hours Operating Temperature -30~-60t Humidity 10%-95% Color Temperature 6500-9500K Transport Package The Factory Packaging Specification 320*160mm Trademark hongking Origin China HS Code 8528591090 Production Capacity 5000 Sqm/YearProduct Description
Full Color Outdoor P10 Led Display For advertising boardProduct descripition:
| Product Model | Outdoor Fixed F10-2S | Outdoor Fixed F8-4S | Outdoor Fixed F6-8S | Outdoor Fixed F5-8S | Outdoor Fixed F4-8S |
| Pixel Pitch | 10 mm | 8 mm | 6 mm | 5 mm | 4 mm |
| Module Size | 320x160 mm | 256x128 mm | 192x192 mm | 160x160 mm | 256x128 mm |
| Module Resolution | 32x16 pixels | 32x16 pixels | 32x32 pixels | 32x32 pixels | 64x32 pixels |
| LED | SMD3535 | SMD3535 | SMD3535 or SMD2727 | SMD2727 | SMD2525 |
| Standard Cabinet Size | 960x960 mm | 1024x1024 mm | 768x768 mm | 960x960 mm | 1024x1024 mm |
| Standard Cabinet Resolution | 96x96 pixels | 128x128 pixels | 128x128 pixels | 192x192 pixels | 256x256 pixels |
| Standard Cabinet | Iron | Iron | Iron | Iron | Iron |
| Physical Density | 10000 Pixels/m2 | 15625 Pixels/m2 | 27777 Pixels/m2 | 40000 Pixels/m2 | 62500 Pixels/m2 |
| White Balance Luminance | ≥6500 nits | ≥7000 nits | ≥6500 nits | ≥6000 nits | ≥6000 nits |
| Gray Scale per Color | 65536 grades gray(16 bit) | 65536 grades gray(16 bit) | 65536 grades gray(16 bit) | 65536 grades gray(16 bit) | 65536 grades gray(16 bit) |
| Contrast | 5000:01:00 | 5000:01:00 | 5000:01:00 | 5000:01:00 | 5000:01:00 |
| Refresh Frequency | ≥3840 Hz | ≥3840 Hz | ≥3840 Hz | ≥3840 Hz | ≥3840 Hz |
| Visual Angle(Horizontal/Vertical) | 140°/140° | 140°/140° | 140°/140° | 140°/140° | 140°/140° |
| Max Power | 600 W/m2 | 650 W/m2 | 900 W/m2 | 1000 W/m2 | 1000 W/m2 |
| Average Power | 200 W/m2 | 250 W/m2 | 300 W/m2 | 350 W/m2 | 350 W/m2 |
| Input Voltage(AC) | 110 V -240 V | 110 V -240 V | 110 V -240 V | 110 V -240 V | 110 V -240 V |
| Working Environment Temperature | -20ºC~50ºC | -20ºC~50ºC | -20ºC~50ºC | -20ºC~50ºC | -20ºC~50ºC |
| Operating Humidity | 10%RH~95%RH | 10%RH~95%RH | 10%RH~95%RH | 10%RH~95%RH | 10%RH~95%RH |
| Control System | AV,Video,VGA,DVI,HDMI,SDI,DP | AV,Video,VGA,DVI,HDMI,SDI,DP | AV,Video,VGA,DVI,HDMI,SDI,DP | AV,Video,VGA,DVI,HDMI,SDI,DP |
