pH10 Outdoor Adverting Wall LED Display/ P10 LED Screen Display
Shenzhen Hongking Optoelectronic Co., Ltd.- Tube Chip Color：Full Color
- IP Rating：IP67
- Pixel Pitch：10mm
- Pixel Configuration：1r1g1b, SMD 3535
- Display Function：Video Display, Image & Text Display, Text Display, Market Display
- Average Power Consumption：220W , m²
Base Info
- Model NO.：Outdoor LED Display P10-2S
- Pixel Density：10000dots,M2
- Scanning Mode：1,2 Scan
- Display Type：LED Video Display
- Application：Stage Performance
- Certification：CE, RoHS, CCC
- Product Name：Outdoor LED Display P10-2s(SMD)
- Driver IC：Mbi5124
- Bightness CD/Sqm：7200CD,M2
- Grey Scale：65536 Degree
- Life Time：More 100, 000 Hours (80%)
- Mtbf：More 50, 000 Hours
- Operating Temperature：-30~-60t
- Humidity：10%-95%
- Color Temperature：6500-9500k
- Transport Package：The Factory Packaging
- Specification：320*160mm
- Trademark：hongking
- Origin：China
- HS Code：8528591090
- Production Capacity：5000 Sqm,Year
Description
Basic Info.
Model NO. Outdoor LED Display P10-2S Pixel Density 10000dots/M2 Scanning Mode 1/2 Scan Display Type LED Video Display Application Stage Performance Certification CE, RoHS, CCC Product Name Outdoor LED Display P10-2s(SMD) Driver IC Mbi5124 Bightness CD/Sqm 7200CD/M2 Grey Scale 65536 Degree Life Time More 100, 000 Hours (80%) Mtbf More 50, 000 Hours Operating Temperature -30~-60t Humidity 10%-95% Color Temperature 6500-9500k Transport Package The Factory Packaging Specification 320*160mm Trademark hongking Origin China HS Code 8528591090 Production Capacity 5000 Sqm/YearProduct Description
pH10 Outdoor Adverting Wall LED Display/ P10 LED Screen Display
| Product Model | Indoor Fixed F6 | Indoor Fixed F5 | Indoor Fixed F4 | Indoor Fixed F3 | Indoor Fixed F2.5 |
| Pixel Pitch | 6mm | 5 mm | 4 mm | 3 mm | 2.5mm |
| Module Size | 192x192mm | 160x160 mm | 256x128 mm | 192x192mm | 160x160 mm |
| Module Resolution | 32x32 pixels | 32x32 pixels | 64x32 pixels | 64x64 pixels | 64x64 pixels |
| LED | SMD3528 | SMD3528 | SMD2121 | SMD2121 | SMD2121 |
| Standard Cabinet Size | 960x960 mm | 960x960 mm | 768x768mm | 576x576mm | 480x480 mm |
| Standard Cabinet Resolution | 160x160 pixels | 192x192 pixels | 192x192pixels | 192x192pixels | 192x192 pixels |
| Standard Cabinet | Iron | Iron | Iron | Iron | Iron |
| Physical Density | 27777 Pixels/m2 | 40000 Pixels/m2 | 62500 Pixels/m2 | 62500 Pixels/m2 | 40000 Pixels/m2 |
| White Balance Luminance | ≥1500 nits | ≥1500 nits | ≥1200 nits | ≥1200 nits | ≥1200 nits |
| Gray Scale per Color | 16384 level | 16384 level | 16384 level | 16384 level | 16384 level |
| Contrast | 1000:01:00 | 1000:01:00 | 1000:01:00 | 1000:01:00 | 1000:01:00 |
| Refresh Frequency | ≥960 Hz | ≥960Hz | ≥960 Hz | ≥960 Hz | ≥960Hz |
| Visual Angle(Horizontal/Vertical) | 140°/140° | 140°/140° | 140°/140° | 140°/140° | 140°/140° |
| Max Power | 600 W/m2 | 600 W/m2 | 650 W/m2 | 650 W/m2 | 700 W/m2 |
| Average Power | 200 W/m2 | 200 W/m2 | 220 W/m2 | 220 W/m2 | 250 W/m2 |
| Input Voltage(AC) | 110 V -240 V | 110 V -240 V | 110 V -240 V | 110 V -240 V | 110 V -240 V |
| Working Environment Temperature | -20ºC~50ºC | -20ºC~50ºC | -20ºC~50ºC | -20ºC~50ºC | -20ºC~50ºC |
| Operating Humidity | 10%RH~95%RH | 10%RH~95%RH | 10%RH~95%RH | 10%RH~95%RH | 10%RH~95%RH |
| Control System | AV,Video,VGA,DVI,HDMI,SDI,DP | AV,Video,VGA,DVI,HDMI,SDI,DP | AV,Video,VGA,DVI,HDMI,SDI,DP | AV,Video,VGA,DVI,HDMI,SDI,DP | AV,Video,VGA,D |
