• Model NO.：P7.62
• System Operating Platform：WIN XP
• Display Type：LED Dot Matrix Display
• Application：Stage Performance, Advertising, Shopping Guide
• IP Rating：IP43
• Certification：CE, RoHS, CCC
• Waterproof：IP43 Front, IP43 Back
• Best Viewing Distance：8-150m
• White Balance Brightness：More Than 3500CD,Sqm
• Horizontal Viewing Angle：120degree
• Working Temperatue：-30degree-+80degree
• Life Span：More Than 100, 000hours
• Power Consumption：350W
• Transport Package：Wooden, Carton and Freight Package
• Specification：CE, RoHS, SGS, etc.
• Trademark：FOXGOLDEN
• Origin：Shenzhen, China.
• HS Code：8528591090
• Production Capacity：4000sqm,Month

No.
Specifications
Project
1.
LED chip
Epistar/Silan/Cree etc...
2.
Physical Pixel Pitch
7.62mm
3.
Physical Pixel Density
17220dots/m2
4.
Pixel composition
SMD,1Red, 1Green,1Blue
5.
Moduel Size
244*122mm
6.
Moduel resolution
32*16dots
7.
Cabinet thickness
< 170 mm
8.
Bracket of cabinet
Easy to install onto the LED cabinet and unistall .
9.
Brightness
≥ 1000cd/ m2
10.
Colors
16.7million
11.
Viewing angle
Horizontal ≥120°,   Vertical  : ≥ 120°
12.
Viewing distance
5m -100m
13.
Scan frequency
≥600 Hz
There will be one receive card in each cabinet  ,so that the LED display wont sparked .
Also it is very easy to move and connetct
14.
Video Frame Rate
≥150 fps
15.

Control method

Controlled by PC, synchronous display
16.
Life span( half brightness)
≥100,000 hours
17.
Weight
25Kg /sqm
18.
Average power consumption
300W/sqm
19.
Peak power consumption
800W/sqm
20.
Input voltage
AC220V/50Hz ±10%    or  AC110V/60Hz ±10%  or AC380V/60Hz ±10%
21.
Operating Environment
Temperature:-20+60      Humidity:10%95%RH
22.
Operating system
Windows 7/Vista
23.
Type of video signal
S-video, composite video ,RGB ,VGA ,DVI

Our Services
1. Guarantee

(1) We guarantee all our displays, modules, parts for two full year. During this time, we will replace or remand our goods for free if there is something wrong with them.
(2) We will provide maintenance for a lifetime and charge for the raw materials only.

2. Technology Training
(1) We provide the technology training for free, which contains the operation training and maintenance training in the factory.
(2) We will send our engineers to your country by negotiation.

3. Maintenance and Consultation
(1) We provide full maintenance for a lifetime and charge for the raw materials only.
(2) We also provide lifetime consultation by E-mail, call, MSN or other ways for free.

4. Documents and Certification
(1) We provide the operation manual, software, test report and so on.
(2) We can also provide all kinds of certification such as CE, UL and so on.

5. CAD Drawing and Fixing
(1) We provide CAD drawing on how to fix up the display for free and some other expert suggestion.
(2) We will send our engineers to your place if we are expected after our negotiation.

6. Additional service
(1) We provide you the forwarding information, and some other information such as flight box, structure information for your reference for free.
