P10 Single Red LED Panel

Shenzhen Foxgolden Technology Limited
  • Tube Chip Color：Single Color
  • IP Rating：IP65
  • Pixel Pitch：10mm
  • Pixel Configuration：Single Red
  • Display Function：Text Display
  • Average Power Consumption：350W , m²

Base Info

  • Model NO.：P10
  • Pixel Density：10000 dot , m²
  • Scanning Mode：1,16 Scan
  • Display Type：LED Video Display
  • Application：Advertising
  • Certification：CE, RoHS, UL, CCC
  • Warranty：3 Years
  • IP Grade：IP 65
  • Best Viewing Disatance：8-200m
  • Refresh Frequency：350Hz
  • Frame Frequency：60Hz
  • Certificate：CE,RoHS
  • Module Size：320*160mm
  • Life Span：100,000hours
  • Mtbf：10000hours
  • LED Chip：Epistar From Taiwan
  • Transport Package：Anti-Shaking Wooden Case or Air Flight Case
  • Specification：CE, RoHS, UL, SGS
  • Trademark：FOXGOLDEN
  • Origin：Guangdong, China
  • HS Code：8528591090
  • Production Capacity：6000sqm,Month

Description

The technology paramete  p10 mm NumberItemP101Pixel pitch10mm2Size of  module320mmX160  mm3Resolution of module32  X164Density of pixel10000dots/m25Pixel configurationR or G or B or 6Red wavelength625± 2nm7Green wavelength525± 2nm8Blue wavelength470± 2nm9Colors1677721610Best viewing distance10-150m11Horizontal viewing angle120°12power consumption200w/m213Brightness> 2000cd /m214Gray scale16bits per color15Color temperature6500k16Control methodSynchronization & Asynchronization17Driving method  constant scanning18Frame frequency60Hz19Refresh frequency> 300Hz20Working voltageAC220V/110V± 10%21IP gradeIP6722Working temperature-20° C~80° C23MTBF> 10000 hours24Life span> 100, 000 hours25Defects rate.≤ 0.00001(Led display line standard< 0.0001)

P10 Single Red LED Panel
