• Model NO.：P16
• Pixel Density：3906dots,Sqm
• Scanning Mode：Static Scan
• Display Type：LED Video Display
• Application：Advertising
• Certification：CE, RoHS, CCC
• Module Size：256*128mm
• Pixel Configuration：1r1g1b
• Power Supply：5PCS
• Best Viewing Angle：12-300m
• Temperature：Working: -35~+85
• Working Voltage：AC220V,110V± 10%
• Refresh Frequency：≥ 400Hz
• Brightness of White Balance：More Than 8000CD,Sqm
• Mtbf：≥ 10, 000hours
• Life Span：≥ 100, 000hours
• Transport Package：Anti-Shaking Wooden Case or Air Flight Case
• Specification：CE, RoHS, UL, SGS
• Trademark：Foxgolden
• Origin：Shenzhen, Guangdong, China
• HS Code：8528591090
• Production Capacity：3000PCS,Month

Technical parameterUnit moduleModule size256*128mmPixel pitch16mmPixel density3904dots/m2Pixel configuration2R1G1BLed specificationΦ 5ellipsePixel resolutionW: 16dots*H: 8dotsCabinetDimension1024mm*768mm*170mmQuantities of module24pcsPower supply5pcsThermal dischargeFan*2pcsTotal weight55kgBest viewing angle12-300mTemperatureStorage: -35~+85Working: -35~+85Thickness17cm can adjustableRemarks: cabinet size can changed, upon project need.PowerWorking voltageAC220V/110V± 10%Average power consumption250-480WMax. Power consumption≤ 560W/sqmCurrent≤ 20mA(single LED)Control systemCPUPentium4 or aboveOperating systemWIN98/2000/NT/XPControl methodSynchronizationMain technical parameterDriving deviceStatic scanningDrive typeConstant Current driver ICRefresh frequency≥ 400HzGrey scale/colors256 levels of each color(R/G/B)/16.7M colorBrightness of white balanceMore than 8000cd/sqmBrightness adjustment256 levels of each color(R/G/B)by softwareOperating ambient humidity10%--95%Video signalPAL/NTSCControl systemDVI display card+full color controller cardMTBF≥ 10, 000hoursLife span≥ 100, 000hoursFlatnessTolerance of interpixel ≤ 0.3mmTolerance of modules clearance≤ 0.6mmPower switchAutomatic switchDisplay mode1024*768Communication distanceUnshielded twisted pair net line transmission distance 100m, max transmission distance 200m.
Multi-mode Optic fiber transmission distance 500m; Single-mode optic fiber transmission distance 10KMSoftwareLED media player

Payment terms:
30% deposit before production, 70% balance before shipping
-T/T:
-Paypal
-Western Union
-Escrow

Packing:
-Standard Export Carton with fully Polyfoam or Pearl Wool
-Flight case;
-Anti-shaking wooden case

Shipping:
LED module: 3 to 5 working days upon receiving deposit payment
LED display: 5 to 8 working days upon receiving deposit payment

After-Sales-Service:
-Lifetime with professional engineer support for free.
-Within 1 year, supply spare parts for free if the machine has quality problem

FAQ

Q1: When is the delivery time?
A1: we will accomplish manufacturing within 10-15 days after receiving the deposit.

Q2: What is the payment method?
A2: We support a variety of payment methods, the most common is the TT.

Q3: Can it play HD video?
A3: Yes, it can realize HD video function with Linsn controlling system.

Q4: What's the controlling system?
A4: Our standard controlling system for this model is Linsn, Novastar. Also support other controlling system, like Xixun,TF, Colorlight, etc.

Q5: How about the size of project?
A5: Please offer the size with "width by height" of project. We will offer the suitable solution for your project size. I will appreciate it if any drawing files about installation offered.

Q6: How about your service?
A6:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
6. Special service for big project, such as stadium, exhibitions, squares and so on.
