• Model NO.：p3- Indoor
• System Operating Platform：WIN XP
• Display Type：LED Video Display
• Application：Stage Performance, Advertising, Shopping Guide
• IP Rating：IP40
• Certification：CE, RoHS, UL
• Module：P3
• Module Size：192*192mm
• Color：1r1g1b
• Brightness：>2000CD Sqm
• Cabinet Number：3*3
• Average Consumption：600W,Sqm
• Best Viewing Distance：3-10m
• Mtbf：10000
• Max Refresh Rate：2800
• Transport Package：Anti-Shaking Wooden Case; Flight Case
• Specification：CE, RoHS
• Trademark：FOXGOLDEN
• Origin：Shenzhen, Guangdong
• HS Code：8528591090
• Production Capacity：4000sqm,Sqm

Basic Info.

Model NO. p3- Indoor System Operating Platform WIN XP Display Type LED Video Display Application Stage Performance, Advertising, Shopping Guide IP Rating IP40 Certification CE, RoHS, UL Module P3 Module Size 192*192mm Color 1r1g1b Brightness >2000CD Sqm Cabinet Number 3*3 Average Consumption 600W/Sqm Best Viewing Distance 3-10m Mtbf 10000 Max Refresh Rate 2800 Transport Package Anti-Shaking Wooden Case; Flight Case Specification CE, RoHS Trademark FOXGOLDEN Origin Shenzhen, Guangdong HS Code 8528591090 Production Capacity 4000sqm/Sqm

Product Description

p3 indoor full color SMD LED screen

Numbers	Technical indexes	Specification
1	Pixel pitch	3mm
2	Module size	192mm×192mm
3	Module resolution	64×64
4	Module density	111111dots/sqm
5	Pixel configuration	RGB,3 in 1
6	Red wavelength	625±2nm
7	Green wavelength	525±2nm
8	Blue wavelength	470±2nm
9	Colors	16777216
10	Best viewing distance	3m---10m
11	Horizontal viewing angle	140°
12	Vertical viewing angle	120°
13	Maximum power consumption	1200W/sqm
14	Average power consumption	600W/sqm
15	Brightness	2000cd/sqm,adjustable
16	Gray scale	16bits of per color
18	Driving method	1/16scanning
19	Frame frequency	60Hz
20	Refresh frequency	300 Hz
21	Working voltage	AC220V/110V±10%
22	IP grade	IP20-45
23	Working temperature	-20°C~80°C
24	MTBF	More than 10,000 hours
25	Life span	More than 100,000hours

Company Description:
FOXGOLDEN GROUP LTD (foxgolden.en.made-in-china.com)is a professional high quality LED display manufacturer. Since 2004, we have been dedicating to the aim that producing high quality products, and now FOXGOLDEN has been well integrated in terms of R&D, produce, project, capital and marketing.
As a company based on market, we are going to be a world wide famous brand in LED display industrial.

Our service:
1. Guarantee
 (1) We guarantee all our displays, modules, parts for two full year. During this time, we will replace or remend our goods for free if there is something wrong with them.
 (2) We will provide maintenance for a lifetime and charge for the raw materils only.

2. Technology Training
(1) We provide the technology training for free, which contains the operation training and maintenance training in the factory.
(2) We will send our engineers to your country by negotiation.

3. Maintenance and Consulation
(1) We provide full maintenance for a lifetime and charge for the raw materials only.
(2) We also provide lifetime consulation by E-mail, call, MSN or other ways for free.

4. Documents and Certification
 (1) We provide the operation manual, software, test report and so on.
 (2) We can also provide all kinds of certification such as CE, UL and so on.

5. CAD Drawing and Fixing
 (1) We provide CAD drawing on how to fix up the display for free and some other expert suggestion.
 (2) We will send our engineers to your place if we are expected after our negotiation.

6. Additional service

 (1) We provide you the forwarding information, and some other information such as flight box, structure information for your reference for free.

Pakage:
LED module: Carton
LED display: Anti-shaking wooden case
                         Flight case

Website:http://foxgolden.en.made-in-china.com
Foxgolden had been engaged in designing and manufacturing LED display for more than 11 years. Our products have certificates like CE/FCC/RoHS/NQA .
The best quality products and excellent service will be provided to you by our professional team.
