P5 Indoor Rental Aluminum LED Sign Board
Shenzhen Foxgolden Technology Limited- Tube Chip Color：Full Color
- Display Function：Video Display
- Pixel Pitch：5mm
- Pixel Configuration：1R,1G,1B
- Pixel Density：40,000 dots , m²
- Scanning Mode：1,8 Scan
Base Info
- Model NO.：p5
- System Operating Platform：WIN XP
- Display Type：LED Video Display
- Application：Stage Performance, Advertising
- IP Rating：IP43
- Certification：CE, RoHS, CCC
- Cabinet Material：Aluminum
- Cabinet Size：640*640mm,960*960mm
- Cabinet Weight：20kg,35kg
- Life Span：>100,000 Hours
- Viewing Angle Vertical/Horizontal：140degree
- Module Size：320*160mm
- Control System：Synchronization , Asynchronization
- Transport Package：1. Wooden Package. 2. Air Flight Case
- Specification：CE&RoHS&UL&SGS
- Trademark：FOXGOLDEN-indoor-P5
- Origin：Guangdong, China
- HS Code：8531200000
- Production Capacity：4000sqm,Month
Description
Technical parameterUnit module Module size 320x160mm Pixel pitch 5mm Pixel density 40000dots/m2 Pixel configuration 1R1G1B Led specification Φ 5ellipse Pixel resolution W: 64dots*H: 32dots Cabinet Dimension 960*960mm*110mm Quantities of module 13pcs Power supply 4pcs Thermal discharge Fan*2pcs Total weight 22.4kg Best viewing angle 3-15m Temperature Storage: -35degree~+85degree Working: -35degree~+85degree Thickness 11cm can adjustable Remarks: cabinet size can changed, upon project need. Power Working voltage AC220V/110V± 10% Average power consumption 400W Max. Power consumption ≤ 800W/sqm Current ≤ 20mA(single LED) Control system CPU Pentium4 or above Operating system WIN98/2000/NT/XP Control method Synchronization Main technical parameter Driving device 1/16 scanning Drive type Constant Current driver IC Refresh frequency ≥ 400Hz Grey scale/colors 256 levels of each color(R/G/B)/16.7M color Brightness of white balance More than 8000cd/sqm Brightness adjustment 256 levels of each color(R/G/B)by software Operating ambient humidity 10%--95% Video signal PAL/NTSC Control system DVI display card+full color controller card MTBF ≥ 10, 000hours Life span ≥ 100, 000hours Flatness Tolerance of interpixel ≤ 0.3mm Tolerance of modules clearance≤ 0.6mm Power switch Automatic switch Display mode 800x800mm Communication distance Network calbe: 100m, Multi-model: 500m, Single-model fiber: 20km Software LED media player
