• Model NO.：FR 3.91
• Cabinet Size (mm)：500*1000
• Refresh Rate (Hz)：3840
• Brightness (Nits)：5000
• Specification：500*1000mm

Basic Info.

Model NO. FR 3.91 Cabinet Size (mm) 500*1000 Refresh Rate (Hz) 3840 Brightness (Nits) 5000 Specification 500*1000mm

Product Description

FR Series Design FR series rental products, standard cabinet size 500x500mm, 500x1000mm, up to 3840hz refresh frequency. The cabinet with radian can be selected. The cabinet can realize the arc splicing effect that the inner radian is 5-10 degrees adjustable and the outer radian is 5 degrees. This series of cabinet is stable and not easy to deform, the surface of the cabinet is anodized, anti-collision, anti friction, suitable for multiple installation and disassembly in the rental process.
FR Series Features
FR series rental products, standard cabinet size 500x500mm,500x1000mm, up to 3840hz refresh frequency. The cabinet with radian can be selected. The cabinet can realize the arc splicing effect that the inner radian is 5-10 degrees adjustable and the outer radian is 5 degrees. This series of cabinet is stable and not easy to deform, the surface of the cabinet is anodized, anti-collision, anti friction, suitable for multiple installation and disassembly in the rental process.
High Precision Die-casting Aluminum Cabinet
High strength, stable and durable cabinet design, not easy to deform. Ensure the accuracy and flatness of cabinets splicing.
Signle Operation Design
Only need one technician to install LED screen. Fast side and handle lock with safe design to prevent the mistakes.
Corner Guard
Anti collision corner protection is added at the four corners of the cabinet to ensure that the module and lamp beads are not damaged and can resist the harsh site environment.
Two Cabinet Size (Option)
Two cabinet sizes available: 500*500/500*1000mm, two cabinets support mix splicing.
HUB Cable-less Connection, Easy to Assemble
Pluggable power cabinet without cable connecting, elegant design. Take a second to remove saving maintain time


Product Model	FR 2.6	FR 2.9	FR 3.9	FR 3.9	FR 4.8
Model Size (mm)	250x250	250x250	250x250	250x250	250x250
Module Resolution (dots)	96x96	84x84	64x64	64x64	52x52
Scanning Mode	1/32	1/28	1/16	1/16	1/13
Cabinet Size (mm)	500x500	500x500	500x500/500x1000	500x500/500x1000	500x500/500x1000
Cabinet Resolution (L*W)	192x192	168x168	128x128/128x256	128x128/128x256	104x104/104x208
Physical Density (dot/sqm)	147,456	112,896	65,536	65,536	43,264
Brightness (cd/sqm)	700~900	700~900	700~1000	3300~5500	3300~5500
Max Power Consumption	650W	650W	650W	800W	800W
Avg Power Consumption	220W	220W	220W	260W	260W
LED Configuration	1R1G1B	1R1G1B	1R1G1B	1R1G1B	1R1G1B
LED Type	SMD1515	SMD1515	SMD1515	SMD1515	SMD1515
Service Way	Front & Rear	Front & Rear	Front & Rear	Front & Rear	Front & Rear
Cabinet Weight (kg)	7.3 kg	7.3 kg	7.3 kg	7.3 kg	7.3 kg
Cabinet Material	Die-casting Aluminum	Die-casting Aluminum	Die-casting Aluminum	Die-casting Aluminum	Die-casting Aluminum
Protection Level	IP65/IP45	IP65/IP45	IP65/IP45	IP65/IP45	IP65/IP45
Contrast Ratio	≥5000:1	≥5000:1	≥5000:1	≥5000:1	≥5000:1
Gray Scale	14bit	14bit	14bit	14bit	14bit
Refresh Rate	3840	3840	3840	3840	3840
Viewing Angle	160/140	160/140	160/140	160/140	160/140
Input Voltage (V)	AC110V~AC220V	AC110V~AC220V	AC110V~AC220V	AC110V~AC220V	AC110V~AC220V
Module Max Current (A)	8.5A	8.5A	8.5A	8.5A	8.5A
Working Temperature (ºC)	-10~50	-10~50	-10~50	-10~50	-10~50
Working Humidity (RH)	10%~95%	10%~95%	10%~95%	10%~95%	10%~95%
Lifetime (Hrs)	≥100,000	≥100,000	≥100,000	≥100,000	≥100,000
