• Model NO.：Outdoor LED Display P10-4S
• Pixel Density：10000 dot , m²
• Scanning Mode：1,4 Scan
• Display Type：LED Video Display
• Application：Advertising
• Certification：CE, CCC, ISO9001
• Product Name：Outdoor LED Display P10-4s
• Driver IC：Mbi5124
• Bightness CD/Sqm：5000CD,M2
• Grey Scale：65536 Degree
• Life Time：More 100, 000 Hours (80%)
• Mtbf：More 50, 000 Hours
• Operating Temperature：-30~-60t
• Humidity：10%-95%
• Color Temperature：6500-9500K
• Transport Package：The Factory Packaging
• Specification：320*160mm
• Trademark：hongking
• Origin：China
• HS Code：8528591090
• Production Capacity：5000 Sqm,Year

Basic Info.

Model NO. Outdoor LED Display P10-4S Pixel Density 10000 dot / m² Scanning Mode 1/4 Scan Display Type LED Video Display Application Advertising Certification CE, CCC, ISO9001 Product Name Outdoor LED Display P10-4s Driver IC Mbi5124 Bightness CD/Sqm 5000CD/M2 Grey Scale 65536 Degree Life Time More 100, 000 Hours (80%) Mtbf More 50, 000 Hours Operating Temperature -30~-60t Humidity 10%-95% Color Temperature 6500-9500K Transport Package The Factory Packaging Specification 320*160mm Trademark hongking Origin China HS Code 8528591090 Production Capacity 5000 Sqm/Year

Product Description

Outdoor Big Advertising Screen LED Billboard P10


1. UL, CE&RoHS&EMC
2. Easy operation, installation
3. High brightness and clear Video
4. Warranty 3 years
5. Good waterproof
6.LED display manufacture
7.Pixel Density: 10000








Product descripition:

Product Model	Outdoor Fixed F10-4S	Outdoor Fixed F8-5S	Outdoor Fixed F6-8S	Outdoor Fixed F5-8S
Pixel Pitch	10 mm	8 mm	6 mm	5 mm
Module Size	320x160 mm	320x160 mm	192x192 mm	160x160 mm
Module Resolution	32x16 pixels	40x20 pixels	32x32 pixels	32x32 pixels
LED	SMD3535	SMD3535	SMD3535 or SMD2727	SMD2727
Standard Cabinet Size	960x960 mm	960x960 mm	768x768 mm	960x960 mm
Standard Cabinet Resolution	96x96 pixels	120x120 pixels	128x128 pixels	192x192 pixels
Standard Cabinet	Iron	Iron	Iron	Iron
Physical Density	10000 Pixels/m2	15625 Pixels/m2	27777 Pixels/m2	40000 Pixels/m2
White Balance Luminance	≥5000 nits	≥6000 nits	≥6500 nits	≥6000 nits
Gray Scale per Color	65536 grades gray(16 bit)	65536 grades gray (16 bit)	65536 grades gray (16 bit)	65536 grades gray(16 bit)
Contrast	5000:01:00	5000:01:00	5000:01:00	5000:01:00
Refresh Frequency	≥1920 Hz	≥3840 Hz	≥3840 Hz	≥3840 Hz
Visual Angle (Horizontal/Vertical)	140°/140°	140°/140°	140°/140°	140°/140°
Max Power	600 W/m2	650 W/m2	900 W/m2	1000 W/m2
Average Power	200 W/m2	250 W/m2	300 W/m2	350 W/m2
Input Voltage(AC)	110 V -240 V	110 V -240 V	110 V -240 V	110 V -240 V
Working Environment Temperature	-20ºC~50ºC	-20ºC~50ºC	-20ºC~50ºC	-20ºC~50ºC
Operating Humidity	10%RH~95%RH	10%RH~95%RH	10%RH~95%RH	10%RH~95%RH
Control System	AV,Video,VGA,DVI, HDMI,SDI,DP	AV,Video,VGA,DVI,HDMI, SDI,DP	AV,Video,VGA,DVI,HDMI, SDI,DP	AV,Video,VGA,DVI,HDMI, SDI,DP

Professional production:
Full Color LED Display,Indoor LED Display,Outdoor LED Display,Rental LED Display,Outdoor SMD LED Display,Outdoor DIP LED Display,Full Color LED Display Module,Single Color LED Display Module,Transparent LED Display,Advertising LED Screen

HONGKING LED display screen can be widely used in retail store, pubs and hotels, shopping center, TV and broadcasting center, worship, theater, auto show, award and corporate show, concert touring, rental and staging, festival and sports event, art exhibition, press conference etc.

FAQ :
1. Q: Can I get some samples?
A: Yes,sample order is available for quality check and market test.
2. Q: What's the delivery time?
A: Usually below 100pcs is 3 days quick delivery.
3. Q: How long is the warranty period ?
A:  Non-artificial damage,  one years warranty
4. Q: Do you have the products in stock?
A: Yes ,of course
5. Q: Freight Cost?
A: The shipping cost depends on different weight;
We will choose the cheapest and safest way according your detail quantities.
6. Q: How does your factory do regarding the quality control?
A: Quality is priority. Every product will be fully assembled and carefully tested before packing and shipping.













Request for LED Display Quote

Please provide the following information so we can offer best service for you . After this we will provide details quote to you as soon as possible.

1,Is your LED Display located Indoor, Semi-Outdoor or Outdoor, Mobile or Trailer (required)
()Indoor  ()Semi-Outdoor  ()Outdoor  ()Mobile  ()Trailer

2,What is the Length of your LED Display requirement  (required)
(  )Metres

3,What is the Height of your LED display  requirement? (required)
(  )Metres

4,What is the Optimal distance viewing to the LED Display? (required)
(  )Metres

5,What will be displayed on the LED display? (required)
()Text  ()Pictures  ()Videos  ()TV/Camera

6,I will usually program the LED display with the following frequency:
()Daily/Weekly & Disconnect  ()Stream Content Continually Online

7,I would like to connect to the LED display using: (required)
()Computer Connection control
()WiFi Connection control
()3G Connection control

Please upload any images that may assist with an understanding of your led display requirement:
Upload Images()

Yours Details
Full Name (required)

Email Address (required)

Contact No (required)

---------------------------------------------------------------------

Thanks and best regards

Tom xie

Shenzhen hongking optoelectronic co.,ltd
Professional production:
Full Color LED Display,Indoor LED Display,Outdoor LED Display,Rental LED Display,Outdoor SMD LED Display,Outdoor DIP LED Display,Full Color LED Display Module,Single Color LED Display Module,Transparent LED Display,Advertising LED Screen
