P10 Outdoor HD DIP Series Display Screen
Shenzhen FWS Technology Co., Ltd.- Tube Chip Color：Full Color
- IP Rating：IP66
- Pixel Pitch：10mm
- Pixel Configuration：1R, 1G, 1B
- Display Function：Market Display
- Average Power Consumption：200W,Square Meter
Base Info
- Model NO.：P10
- Pixel Density：10000 dot , m²
- Scanning Mode：1,4 Scan
- Display Type：Segment LED Display
- Application：Shopping Guide
- Certification：CE, CCC
- Warranty Period：2years
- Deliver Time：15-20 Days
- Drive Type：Constant Drive
- Life Span：100000 Hours
- Best Viewing Angle：110,55
- Best Viewing Distance：6m-40m
- Modle Size：160mm*160mm
- Package Mode：SMD 3535
- LED：Black LED
- Transport Package：Die-Casting Aluminum Case,Flight Case
- Specification：1280mm*1280mm
- Trademark：FWS
- Origin：Shenzhen China
- HS Code：9405409000
- Production Capacity：25000sqm,Month
Description
Tehnical parameterPanel Dimension (w) 160mm*160mmH) Pixel pitch 10mm Pixel Density 10000 DOTS/M2 Pixel configuration 1R1G1B LED specification SMD 3535 Port type HUB75-A Pixel resolution 16*16 dots Average power 20W Panel weight 0.37KG Cabinet&Bracket Quantity of panel 64PCS Weight for bracket 223.68KG Gray scale levels 16bit Best viewing distance 110/55 Best viewing angle 6-40 Meter Working temperture -20-±65 Panel power supply 5V40A Screen power supply AC220V-AC250V Max power 600W/M2 Average power 200W/M2 Tehnical parametr Driving device Constant current drive Drive type 1/4 Scanning Refresh frequency >300HZ Display color 4096*4096*4096 Brightness 6500 mcd/M2 Life span 100000 Hours Communicaion distance <100 Meter
