• Model NO.：Indoor p7.62
• System Operating Platform：WIN XP
• Display Type：LED Video Display
• Application：Stage Performance, Advertising, Shopping Guide
• IP Rating：IP43
• Certification：CE, RoHS, UL, CCC, ETL
• Product Name：P7.62-8s Indoor LED Display
• Grey Scale：65536 Degree
• Bightness CD/Sqm：1500
• Mtbf：More 50, 000 Hours
• Life Time：More 100, 000 Hours (80%)
• Driver IC：Mbi5124
• Operating Temperature：-30~-60t
• Humidity：10%-95%
• Color Temperature：6500K-9500K
• Transport Package：The Factory Packaging
• Specification：244*244mm
• Trademark：Hongking
• Origin：China
• HS Code：8528591090
• Production Capacity：5000 Sqm,Year

NO.:Product nameP7.62 led display screen1Pixel Pitch(mm)7.62mm2Pixel configuration1R1G1B/SMD3528 lamp3Pixel density17222dots/m24Brightness 1500 cd/m25Module size(W*H)244*244mm6Module Resolution (W*H)32dots x 32dots7Module weight400g8Cabinet size (W*H)732mm×732mm9Drive ICMBI512410Drive mode1/8scan11Viewing Angle(V/H)140 ºC12Grey Scale65536 degree13Life time>100,000 Hours (50%)14MTBF>50,000 Hours15Operating VoltageAC110V/220V±10%17Screen Power ConsumptionMax: 680w/m2; Average:210w/m218Input Power Frequency50/60Hz19Operating temperature -30--60ºC20Humidity10%-95%21Refresh Rate≥1920HZ22Control MethodSynchronized with computer monitor23Color Temperature6500K-9500K  24LED control systemLINSN,Nova-star,Colorlight is selectable25Control Distance100 m (no repeating); Optical fiber transmission: 500m- 15km26Accepting signal with video processorPAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI27Systems Operating PlatformWindows Xp / Windows 7 / windows 8 /8.1 / windows 10



Company descripition:
HONGKINGLED is a publicly listed LED display manufacturer. Our facilities cover an area of 1000 square meters. Our company strives to deliver stunning LED solutions that can satisfy all customer requirements. Standardization and flexible production allow us to offer competitive prices for a wide range of high quality products. Our valued clients can enjoy the benefits of attentive service and prompt delivery. For the past 6 years, we have made steady progress. Ingenuity and perseverance have firmly established us as pioneers in the LED display industry. Our company is dedicated to the research and development of LED related technologies. HONGKINGLED products are approved by CE, CCC, EMC and FC. We are fully
