• Model NO.：P3 led display
• Pixel Density：111111 Dots,M2
• Scanning Mode：1,4 Scan
• Display Type：LED Video Display
• Application：Advertising
• Certification：CE, RoHS, CCC, ISO9001
• Product Name：Outdoor LED Display P3
• Driver IC：Mbi5124
• Bightness CD/Sqm：5000CD,M2
• Grey Scale：65536 Degree
• Life Time：More 100, 000 Hours (80%)
• Mtbf：More 50, 000 Hours
• Operating Temperature：-30~-60t
• Humidity：10%-95%
• Color Temperature：6500-9500K
• Transport Package：The Factory Packaging
• Specification：192*192mm
• Trademark：hongking
• Origin：China
• HS Code：8528591090
• Production Capacity：5000 Sqm,Year

Technical parameter1Pixel Pitch(mm)3 mm2Pixel configuration1R1G1B/SMD19213Pixel density111111dots/sqm 4Brightness ≥6000cd/sqm5Module size(W*H)192mm×192mm6Module Resolution (W*H)64dots x 64dots7Module weight500g8Cabinet size (W*H)576mm×576mm/960mm×960mm9Led lamp National star 10Drive ICMBI512411PCB 1.6mm 4 layer pcb 12Drive mode1/16scan13Viewing Angle(V/H)140ºC14Grey Scale65536 degree15Life time>100,000 Hours (50%)16MTBF>50,000 Hours17Operating VoltageAC110V/220V±10%18Screen Power ConsumptionMax: 800w/sqm ; Average:260w/sqm19Input Power Frequency50/60Hz20Operating temperature -30--60ºC21Humidity10%-95%22Refresh Rate≥1920HZ23Control MethodSynchronized with computer monitor24Color Temperature6500K-9500K25LED control systemLINSN,Nova-star,Colorlight is selectable26Control Distance100 m (no repeating); Optical fiber transmission: 500m- 15km27Accepting signal with video processorPAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI28Systems Operating PlatformWindows Xp / Windows 7 / windows 8 /8.1 / windows 10
