P6mm Indoor Video Display LED Wall
Shenzhen Seny Technology Co., Ltd.- Tube Chip Color：Full Color
- Display Function：Video Display
- Pixel Pitch：6mm
- Pixel Configuration：1R,1G,1B
- Pixel Density：27,777 dots , m²
- Scanning Mode：1,8 Scan
Base Info
- Model NO.：PH6mm
- System Operating Platform：Win7 XP Vista
- Display Type：LED Video Display
- Application：Shopping Guide
- IP Rating：IP40
- Certification：CE, RoHS, CCC, FCC
- Warranty：One Year Warranty After Shipping
- Transport Package：Wooden Box or Flight Case
- Specification：CE, RoHS, FCC
- Trademark：SENY
- Origin：Shenzhen, Guandong, China
- HS Code：8528591090
- Production Capacity：5000sq. M,Month
Description
Technical parametersS/N Module Specification 1 Pixel Pitch 6mm 2 Pixel Configuration 1R1G1B 3 LED Type SMD 3IN1 4 LED Wavelength R(620-630nm) IV(150-200mcd)
G(520-525nm) IV(260-330mcd)
B(465-470nm) IV(55-65mcd) 5 Pixel Density 27777 pixel dots/s.q.m 6 Module Size(W X H) 192mm x 96mm 7 Module Resolution( W X H) 32 pixel dots x 16 pixel dots 8 Input Voltage(DC) 5V +/- 5% 9 Cabinet Specification 10 Cabinet Size(W X H) 768mm x 576mm 11 Cabinet Resolution(W X H) 128 pixel dots x 96 pixel dots 12 Unit Cabinet Weight 30kg(without packaging) 13 Thickness 135MM 14 Whole Screen Specification 15 Screen Brightness Min. 2200nits/s.q.m 16 Driving Mode Constant current 1/8 driving 17 H/V Visual Angle 120 deg./55 deg. 18 Minimum Viewing Distance 6m 19 Max. Power Consumption 1000W/s.q.m 20 Average Power Consumption 750W/s.q.m 21 Gray Level 4096 levels 22 Frame Frequency Min. 60Hz 23 Refresh Frequency Min. 400Hz 24 Blind Spot Rate Max. 1/10000 25 Protective Scale IP20 26 Screen Plainness Max. +/- 1mm 27 Power Supply Mode AC220 +/- 10% 50Hz/AC110 +/- 10% 60Hz 28 Environment Temperature & Humidity Temperature -20 Celsius degree~+60 Celsius degree
Humidity 10%~90% RH 29 Control System 30 Operating Environment Operating system
Chinese/English Windows98/me/2000/NT/XP
Hardware Configuration
Pentium 300MHz or above
ROM 64M
Graphics Card Standard VGA 256mode or above
Related Software
Microsoft Media player compulsory
OFFICE2000 in case of *. doc files
RealPlayer in case of RealPlayer files 31 Software LED Studio 32 Control Mode Synchronization display(work with computer) 33 Control System DVI video card + full color control card + fiber system( optional) 34 Display Content Video DVD, VCD, TV, image, texts.etc. 35 Interface Standard Ethernet 36 Transmission Distance CAT5 cable:<100 m; Single fiber:<10 km
