P6.25 SMD Outdoor Waterproof Rental LED Video Wall Panel with High Refresh Rate

Shenzhen BST Industry Co., Limited
  • Tube Chip Color：Full Color
  • IP Rating：IP65
  • Pixel Pitch：6.25mm
  • Pixel Configuration：1R, 1G, 1B
  • Display Function：Video Display
  • Average Power Consumption：300W , m²

Base Info

  • Model NO.：P4.81, P5.95, P6.25
  • Pixel Density：25600pixels,Sqm
  • Scanning Mode：1,10 Scan
  • Display Type：LED Video Display
  • Application：Stage Performance
  • Certification：CE, RoHS, UL, CCC, ETL
  • Delivery Time：15~25 Working Days
  • Warranty Time：2 Years
  • Cabinet Size：500X500mm
  • OEM：Yes
  • Transport Package：Flight Case, Plywood Case, Carton.
  • Specification：CE, ROHS, ISO9001
  • Trademark：BST
  • Origin：Shenzhen, China
  • HS Code：8528591090
  • Production Capacity：3000sqm,Month

Description

ModelOR-6.25Pixel Pitch6.25mmPixel Density25600 pixels/m2LED TypeSMD3535/SMD2727LED Configuration1R1G1BCabinet Dimension500mmx500mmCabinet Resolution80*80pixelsCabinet Weight8kgCabinet Materialdie casting aluminumIngress Protection(front/rear)IP65/IP54Brightness>6000nitsViewing Angle(H/V)140°/140°Driving Method1/10 ScanFrame Refresh≥ 60HzData Refresh Rate>1500HzGray Scale16bitPower Consumption(avg.)300w/m2Input VoltageAC 110/220±10%,  50~60HzTemperature(operating/storage)-20~50°C / -40~60°CHumidity(operating/storage)10%~90%RH / 10%~85%RHMTBF≥1000hrsLife Span≥50000hrsPixel Failure<0.0003
