P5 Module Outdoor Indoor LED Display Screen Signage for Advertising

Shenzhen Hongking Optoelectronic Co., Ltd.
  • Tube Chip Color：Full Color
  • IP Rating：IP65
  • Pixel Pitch：5mm
  • Pixel Configuration：1R, 1G, 1B
  • Display Function：Video Display, Image & Text Display, Text Display, Market Display
  • Average Power Consumption：350W , m²

Base Info

  • Model NO.：P5-8S outdoor led display
  • Pixel Density：40000dots,M2
  • Scanning Mode：1,8 Scan
  • Display Type：LED Video Display
  • Application：Advertising
  • Certification：CE, CCC, ISO9001
  • Product Name：Outdoor LED Display P5-8s
  • Driver IC：Mbi5124
  • Bightness CD/Sqm：More 6000CD,M2
  • Grey Scale：65536 Degree
  • Life Time：More 100,000 Hours (80%)
  • Mtbf：More 50,000 Hours
  • Operating Temperature：-30~-60t
  • Refresh Rate：1920Hz
  • Color Temperature：6500-9500K
  • Cabinet Size：960mm*960mm
  • Transport Package：The Factory Packaging
  • Specification：160*160mm
  • Trademark：hongking
  • Origin：China
  • HS Code：8528591090
  • Production Capacity：5000 Sqm,Year

Description

Technical  SpecificationsNOProduct nameoutdoor smd 3535  led display1Pixel Pitch(mm)5mm2Pixel configuration1R1G1B/ smd35353Pixel density40000dots/m24Brightness 6000cd/m25Module size(W*H)160mm * 160mm6Module Resolution (W*H)32 dots x 32dots7Module weight450g8Cabinet size (W*H)960mm×960mm9Drive ICMBI512410Drive mode1/8 scan11Viewing Angle(V/H)140ºC12Grey Scale65536 degree13Life time>100,000 Hours (50%)14MTBF>50,000 Hours15Operating VoltageAC110V/220V±10%17Screen Power ConsumptionMax: 680w/m2; Average:220w/m218Input Power Frequency50/60Hz19Operating temperature -30--60ºC20Humidity10%-95%21Refresh Rate≥1200HZ22Control MethodSynchronized with computer monitor23Color Temperature6500K-9500K24LED control systemLINSN,Nova-star,Colorlight is selectable25Control Distance100 m (no repeating); Optical fiber transmission: 500m- 15km26Accepting signal with video processorPAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI27Systems Operating PlatformWindows Xp / Windows 7 / windows 8 /8.1 / windows 10P5 Module Outdoor Indoor LED Display Screen Signage for Advertising
P5 Module Outdoor Indoor LED Display Screen Signage for Advertising
P5 Module Outdoor Indoor LED Display Screen Signage for Advertising


Professional production:
Full Color LED Display,Indoor LED Display,Outdoor LED Display,Rental LED Display,Outdoor SMD LED Display,Outdoor DIP LED Display,Full Color LED Display Module,Single Color LED Display Module,Transparent LED Display,Advertising LED Screen


FAQ :
1. Q: Can I get some samples?
A: Yes,sample order is available for quality check and market test.
2. Q: What's the delivery time?
A: Usually below 100pcs is 3 days quick delivery.
3. Q: How long is the warranty period ?
A:  Non-artificial damage,  one years warranty
4. Q: Do you have the products in stock?
A: Yes ,of course
5. Q: Freight Cost?
A: The shipping cost depends on different weight;
We will choose the cheapest and safest way according your detail quantities.
6. Q: How does your factory do regarding the quality control?
A: Quality is priority. Every product will be fully assembled and carefully tested before packing and shipping.
