• Model NO.：P16
• Pixel Density：10000 dot , m²
• Scanning Mode：1,2 Scan
• Display Type：LED Video Display
• Application：Advertising
• Certification：CE, RoHS, UL, CCC, ETL
• Repair Access：Both Front Access and Rear Access
• Driver IC：Mbi5124
• Connector：Lk,Nuetrick,Seetronic,Invisible
• Power Supply：MW
• Brightness：>7500 Nits
• Cabinet：Steel,Aluminium
• LED Brand：Nationstar,CREE
• LED Chip：Epistar,CREE
• Refresh Rate：>1920 Hz
• Grey Scale：16 Bits
• Transport Package：Plywood Cases
• Trademark：LEDventure
• Origin：China
• HS Code：852859109
• Production Capacity：4000m2,Month

Basic Info.

Model NO. P16 Pixel Density 10000 dot / m² Scanning Mode 1/2 Scan Display Type LED Video Display Application Advertising Certification CE, RoHS, UL, CCC, ETL Repair Access Both Front Access and Rear Access Driver IC Mbi5124 Connector Lk/Nuetrick/Seetronic/Invisible Power Supply MW Brightness >7500 Nits Cabinet Steel/Aluminium LED Brand Nationstar/CREE LED Chip Epistar/CREE Refresh Rate >1920 Hz Grey Scale 16 Bits Transport Package Plywood Cases Trademark LEDventure Origin China HS Code 852859109 Production Capacity 4000m2/Month

Product Description

1. Basic information
Outdoor full color large led video screen for commercial advertising, socredboard, outdoor medias,  including 4mm/5mm/6mm/8mm/10mm/16mm, the standard cabinet usually 960x960mm/1024*1024MM
- High brightness options for outdoor viewing.
- Stable driver IC solution.
- Standard Cabinet 960x960mm
- Long life span.
- Cost effective solutions.


2.  Technical parameters - Outdoor full color large led video screen

PARAMETERS	DESCRIPTION
Brightness	≥8000 Nits
Viewing angle	H: 120°; V: 60°
Panel weight	45 kg
Panel size	W 960mm x H960mm x D100mm
Panel material	Aluminum
Ingress protection	Front/Rear: IP65/IP54
Operating Temperature/Humidity	-20ºC - +50ºC/ 10-90%RH
Storage Temperature/Humidity	-40ºC - +60ºC/ 10-90%RH
Pixel configuration	1R1G1B
Pixel Pitch	16mm
Pixels per panel	60x60Dots
Physical density	3906 pixels / m 2
Recommended viewing distance	16M
Color	4.4 trillion
Gray scale	65536 levels per color
Brightness control	256 levels of each color(manually),8 levels of each color(automatically)
Contrast ratio	1000:1
Processing depth	16bits
Video frame rate	3840Hz
Input voltage	110-220VAC+-10%
Input power frequency	50-60Hz
Input power <max>	400watts
Input power <typical>	110watts
Life Time	≥100,000 Hours
LED Wavelength	R:620-625nm  G:520-523nm  B:470-473nm
Driving Method	1/1 scan
LED Encapsulation	DIP346
Input signal	RF,S-VIDEO,RGBHV,YUV,YC & COMPOSITION, etc
Certifications	CCC,CE,FCC,ETL,IP65,EMC

3. Outdoor full color large led video screen and control system.
A complete set of outdoor full color large led video screen including led modules, power supplies, cabinets, control system, etc, LEDventure provide a whole compete solutions for customers.


4. Outdoor full color large led video screen sizes available.
Outdoor full color large led video screen sizes are not limited by technology, small size as a few square meters, big as thousands square meters are no problems, also, we can provide customers gold radio 4:3 or 16:9 resolutions.



5. Outdoor full color large led video screen installation.
Outdoor full color large led video screen for commercial advertising, scoreboard, outdoor media, installation usually fixed on the structure, pillar type, mounted on the building etc.


6. Certificates
Our outdoor full color large led video screen quality pass CE, EMC, UL FCC tests, meet the standard of the local market requires

7.FAQ
Important Knowledge of LED Display
1. What about your pre-sale service and post-sale service?
For pre-sale service: We have a professional sales team and a 8 years technical team who are willing to answer your question 24/7. We can offer a whole complete solution for your project!
 For post-sale service: We can instruct you how to use, adjust the screens, and change the boken modules with spare parts.
Also, we can send technicals to your country to solve problems. Mostly, our led display will not have big problems within warranty time!

2. Whats your payment term? How long it takes to delivery?
We accept T/T and L/C, For both T/T and L/C, At least 40% deposit in advance, and the rest 60% before delivery.
Our average Production time is 15 days, after receiving the deposit.

3. What's the control system?
 For synchronization control: We use Nova, Linsn Or Colorlight control system.
 For  asynchronous control: We use Onbon, or Xixun control system.

4. How can i place an order?
Please inform your requirements as clear as possible. So we can send you the offer ASAP.it is better to contact us with Skype/email /phone within project begining, in case of any delays.

5. What kind of display we provide?
 We have indoor/outdoor/mobile LED /rental LED display /LED stage/LED Dance Floor/Irregular LED display/stadium LED Display for you choose.
