High Density Seamless SMD LED Display Panel 500X500mm P2.976 P3.91 Indoor Screen with Fast Locks

Hefei Yilan Electronics Technology Co., Ltd.
  • Tube Chip Color：Full Color
  • Display Function：Video Display, Image & Text Display, Text Display, Market Display
  • Pixel Pitch：2.976mm
  • Pixel Configuration：1R,1G,1B
  • Pixel Density：112896 Dots,Sqm
  • Scanning Mode：1,28 Scan

Base Info

  • Model NO.：P2.976 Indoor
  • System Operating Platform：WIN XP
  • Display Type：LED Video Display
  • Application：Stage Performance, Advertising, Shopping Guide
  • IP Rating：IP20
  • Certification：CE, RoHS, CCC
  • Cabinet Material：Die-Casting Aluminum
  • Cabinet Size：500X500mm,500X1000mm
  • Input Power：100-240V, 50-60Hz
  • Refresh Rate：1920Hz-3840Hz
  • Control System：Novastar,Colorlight
  • Screen Dimension：Customized
  • Brightness：800-1000CD,Sqm
  • Life Span：100,000 Hours
  • Maintenance Mode：Front and Rear Service
  • Warranty：2 Years
  • Transport Package：Flight Case or as Required
  • Specification：250x250mm
  • Trademark：Seekstarled
  • Origin：China
  • HS Code：8528591090
  • Production Capacity：2000 Sqm,Month

Description

Rental Full Color LED DisplayProduct Item Indoor P2.976Indoor P3.91Indoor P4.81Outdoor P3.91Outdoor P4.81Pixel Pitch 2.976mm3.91mm4.81mm3.91mm4.81mmLED Type LED RGB 3in1RGB 3in1RGB 3in1RGB 3in1RGB 3in1LED Life LED 100,000 hours100,000 hours100,000 hours100,000 hours100,000 hoursConfiguration SMD1515SMD2121SMD2121SMD 1921SMD 2727Module Size 250 x 250250 x 250250 x 250250 x 250250 x 250Module Resolution 84*8464*6452*5264*6452*52Pixels Density (dots)11289665536432646553643264Brightness (cd/sqm) 800-1000cd/sqm800-1000cd/sqm800-1000cd/sqm≥5000 cd/sqm≥4000 cd/sqmViewing Distance ≥9m≥9m4-40m≥8m≥8mViewing Angle 120°/120°120°/120°120°/120°120°/120°120°/120°Refresh Rate ≥1920HZ≥1920HZ≥1920HZ≥1920HZ≥1920HZGray Scale 16bit. Red, Green and Blue  each 16K16bit. Red, Green and Blue  each 16K16bit. Red, Green and Blue  each 16K16bit. Red, Green and Blue  each 16K16bit. Red, Green and Blue  each 16KColor Temperature 3200K-9300K adjustable3200K-9300K adjustable3200K-9300K adjustable3200K-9300K adjustable3200K-9300K adjustableScan Mode 1/28 scan1/16 scan1/13 scan1/16 scan1/9 scanCabinet Material die-casting aluminumdie-casting aluminumdie-casting aluminumdie-casting aluminumdie-casting aluminumCabinet Size (mm) 500x500 / 500x1000500x500 / 500x1000500x500 / 500x1000500x500 / 500x1000500x500 / 500x1000Cabinet Weight(kg) 8kg / 14kg8kg / 14kg8kg / 14kg8kg / 14kg8kg / 14kgMax Consumption (W/sqm)700700780680680Ave Consumption (W/sqm) 260260270270270Supply Voltage AC220V/50HZ; AC110V/60HZAC220V/50HZ; AC110V/60HZAC220V/50HZ; AC110V/60HZAC220V/50HZ; AC110V/60HZAC220V/50HZ; AC110V/60HZStorage Temperature -20ºC~+60ºC-20ºC~+60ºC-20ºC~+60ºC-20ºC~+60ºC-20ºC~+60ºCWorking Temperature -20ºC~+50ºC-20ºC~+50ºC-20ºC~+50ºC-20ºC~+50ºC-20ºC~+50ºCOperating Humidity 10%-80%10%-80%10%-80%10%-80%10%-80%IP Rating IP20IP20IP20IP65IP65Display Capacity Text, Graph and VideoText, Graph and VideoText, Graph and VideoText, Graph and VideoText, Graph and VideoControl System LINSN,Nova-star Colorlight (adjustable)LINSN,Nova-star Colorlight (adjustable)LINSN,Nova-star Colorlight (adjustable)LINSN,Nova-star Colorlight (adjustable)LINSN,Nova-star Colorlight (adjustable)Control Mode Synchronous Control ModeSynchronous Control ModeSynchronous Control ModeSynchronous Control ModeSynchronous Control ModeHigh Density Seamless SMD LED Display Panel 500X500mm P2.976 P3.91 Indoor Screen with Fast LocksHigh Density Seamless SMD LED Display Panel 500X500mm P2.976 P3.91 Indoor Screen with Fast LocksCompany Introduction:

High Density Seamless SMD LED Display Panel 500X500mm P2.976 P3.91 Indoor Screen with Fast LocksHigh Density Seamless SMD LED Display Panel 500X500mm P2.976 P3.91 Indoor Screen with Fast LocksHigh Density Seamless SMD LED Display Panel 500X500mm P2.976 P3.91 Indoor Screen with Fast LocksHigh Density Seamless SMD LED Display Panel 500X500mm P2.976 P3.91 Indoor Screen with Fast Locks
High Density Seamless SMD LED Display Panel 500X500mm P2.976 P3.91 Indoor Screen with Fast Locks
FAQ:

1 - May I know the Minimum order for your products?
1sqm.The price is negotiable for large quantity.

2 - Can I get some samples?
Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

3 - Is it OK to print my logo on led display product?
Yes. Please inform us formally before our production and confirm the design firstly based on the sample.

4 - How about the lead time?
LED Module:1-7working days LED Display: 5-20working days.
Mass production time depends on the order quantity.

5 - How to deal with the product faulty?
Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.1%.
Secondly, during the guarantee period, we will send new spare parts with order for small quantity. For defective batch products, we will repair them and resend them to you asap or we can discuss the solution including re-call according to real situation.

6 - What services can we provide?
Delivery Terms: FOB,CIF,EXW, DDU, DDP.
Payment Type: T/T,Money Gram,Western Union,Cash and Credit Card.

7 - What can you buy from us?
LED display, LED screen, LED sign, LED panel, LED modules, LED billboard,etc.

8 - What technical supports can you offer?
We provide all kinds of technology training for free, including the operation, installation and maintenance training of the LED screens.

9 - How Can We Guarantee Quality?
Seven quality control steps ensure your ordered screens good:
Suppliers are long-term cooperated large famous company.
Material check by well-trained staff and machines.
48-hour aging test for all modules before assembling.
Test every panel's function after assembling by engineers and machines.
72-hour aging test for whole screen before shipment.
All details final inspection again before package.
