Outdoor Sport Advertising P10 SMD3535 Module LED Display

Shenzhen Hongking Optoelectronic Co., Ltd.
  • Tube Chip Color：Full Color
  • IP Rating：IP65
  • Pixel Pitch：10mm
  • Pixel Configuration：1R, 1G, 1B
  • Display Function：Video Display, Image & Text Display, Text Display, Market Display
  • Average Power Consumption：220W , m²

Base Info

  • Model NO.：LED Display P10-4S(SMD)
  • Pixel Density：10000 dot , m²
  • Scanning Mode：1,4 Scan
  • Display Type：LED Video Display
  • Application：Advertising
  • Certification：CE, RoHS, CCC, ISO9001
  • Product Name：Outdoor LED Display P10-4s(SMD)
  • Driver IC：Mbi5124
  • Bightness CD/Sqm：5800CD,M2
  • Grey Scale：65536 Degree
  • Life Time：More 100, 000 Hours (80%)
  • Mtbf：More 50, 000 Hours
  • Operating Temperature：-30~-60t
  • Refresh Rate：1920Hz
  • Color Temperature：6500-9500K
  • Warranty：3 Years
  • LED Lamp：Nationstar SMD3535
  • Transport Package：The Factory Packaging
  • Specification：320*160mm
  • Trademark：hongking
  • Origin：China
  • HS Code：8528591090
  • Production Capacity：5000 Sqm,Year

Description

Product nameReliable Outdoor Advertising P10 Modules LED DisplayPixel Pitch(mm)10mmPixel configuration1R1G1BDrive ICMBI5124Screen Power ConsumptionMax: 680w/m2; Average:220w/m2Module Resolution (W*H)32dots x 16dotsLED control systemLINSN,Nova-star,Color light is selectableControl Distance100 m (no repeating); Optical fiber transmission: 500m- 15kmSystems Operating PlatformWindows Xp / Windows 7 / windows 8 /8.1 / windows 10Accepting signal with video processorPAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI
Outdoor Sport Advertising P10 SMD3535 Module LED Display
Outdoor Sport Advertising P10 SMD3535 Module LED Display
Outdoor Sport Advertising P10 SMD3535 Module LED Display
about the installation commissioning ;
after project confirm ,we will provide detailed  construction install drawing
when we finished screen will aging tesing 72 hours ;
you can come and visit make sure quality then we can training
if you wont come we can provide remote control .
if necessary ,we can also appoint engineers to your site ;

Display the installation and debugging, not as difficult as you think;
After the factory production is completed, we will debug the product well,
Send connected pictures and drawings to you at the same time;
