• Model NO.：2.6mm, 2.9mm, 3.91mm
• Pixel Configuration：1R,1G,1B
• Pixel Density：65536 Pixels,Sqm
• Scanning Mode：1,16 Scan
• System Operating Platform：Win XP , Win 7 , Win 8
• Display Type：LED Video Display
• Application：Stage Performance, Advertising, Shopping Guide
• IP Rating：IP43
• Certification：CE, RoHS, CCC
• Delivery Time：20working Days
• Warranty Time：2 Years
• Cabinet Size：500X500mm
• OEM：Yes
• Color：Full Color
• Brightness：>1200nits
• Refresh Rate：>1920Hz
• Material：Die-Casting Alumium
• Transport Package：Flight Case
• Specification：CE, ROHS, ISO9001
• Trademark：BST
• Origin：Shenzhen, China
• HS Code：8528591090
• Production Capacity：5000sqm,Month
• Package size per unit product：50.00cm * 100.00cm * 8.00cm
• Gross weight per unit product：13.000kg

LED Display Series

BST-IRB-2.6

BST-IRB-2.9

    BST-IRB-3.9

Pixel Pitch(mm)

2.604

2.97

         3.9

Pixel Density(dots/m²)

147465

112896

       65536

Avr Power Consumption (W/M²)

              ≤500

              ≤500

         ≤500

Brightness Max(cd/m²)

≥1000

≥1000

         ≥1000

Color Temperature(after calibration)K

6500

6500

          6500

Cabinet Material

Die Casting Aluminum

Die Casting Aluminum

  Die Casting Aluminum

Weight(kg/Panel⁾

10

10

              10

      Working Humidity

          10%-95%

         10%-95%

        10%-95%

      Driving Method

             1/8

             1/13

          1/10

LED Type

SMD2121

SMD2121

          SMD2121

Horizontal/Vertical Viewing Angle(º)

H140º/V140º

H140º/V140º

        H140º/V140º

Recommended Viewing Distance(m)

1--100

1-100

            1--100

Power Supply

Single power

Single power

        Single power

Refresh Rate(Hz)

≥1920

≥1920

            ≥1920

         Weight(kg/m²)

             40

            40

          40

Grey Scale(bit)

R'G'B 16bit

R'G'B 16bit

           R'G'B 16bit

Frame Rate(Hz)

50/60

50/60

           50/60

Life Time(H)

≥100000

≥100000

            ≥100000

Protection

Indoor

Indoor

            Indoor

Cabinet Size(W*H)(mm)

           500x1000

           500X1000

           500X1000

        LED Chip

           Epistar

          Epistar

           Epistar

      Contrast

            4000:1

           4000:1

          4000:1

Protection

IP40

IP40

IP40

Max Power Consumption(W/M²)

900

900

             900

Working Temperature

-20C°/40C°

-20C°/40C°

            -20C°/40C°

Module Size(W*H)(mm)

250X250

250X250

            250X250

        Driving Chip

        ICN2153

       ICN2153

        ICN2135

Control Input

DVI/HDMI/HDSDI

DVI/HDMI/HDSDI

     DVI/HDMI/HDSDI

Max Hanging(Vertical)

≥200kg

≥200kg

            ≥200kg

We guarantee all our displays, modules, parts for two full years. During this time, we will replace or amend all our goods for free if there is something wrong with them. We provide lifetime maintenance and charge only for the raw materials. We provide technology training for free, which contains the operation and maintenance training of the LED screens in the factory. We also provide the operation manual, software, test report and so on. Any associated CAD drawing on how to fix up the display and some other expert suggestion will be provided.

Technology Training

1. We provide the technology training for free, which contains the operation training and maintenance training in the factory.

2. We will send our engineers to your country by negotiation.

CAD Drawing and Fixing

1. We provide CAD drawing on how to fix up the display for free and some other expert suggestion.

2. We will send our engineers to your place if we are expected after our negotiation.

Additional service:

We provide you the forwarding information, and some other information ,such as flight box, structure information for your reference for free.


Why choose BST?

1. BST is a professional manufacturer of LED display screens over 8 years. We have strong R&D to ensure high end products with user-friendly design .
2. The prices are very competitive due to our large-scale procurement of raw material.   We can help you to win more orders if you are distributors.End users will also be satisfied with our quality and price.
3. We have CE, FCC and Rohs certificates. Our products are exported over 85 countries .We have rich experience in handling all possible problems when you import goods from China .
4. We have a wide variety of products for you to choose from .All products are strictly tested before release to market and we test every LED screen 72 hours before delivery.
5. Our sales are well trained to offer professional advice on your specific projects. Processional engineers are on standby, can offer guidance, on site technical support as requested.
6. We offer 2-3 years warranty and life time maintenance .Even when warranty time expires , we only charge material costs
