• Model NO.：P8mm
• Pixel Density：15625 Dots,M2
• Scanning Mode：1,4 Scan
• Display Type：LED Video Display
• Application：Advertising
• Certification：CE, RoHS, CCC
• Warranty：Warranty Is One Year After Shipping
• Transport Package：Export Wooden Box or Flight Case
• Specification：CE, ROHS
• Trademark：SENY
• Origin：Shenzhen, Guangdong, China
• HS Code：8528591090
• Production Capacity：5000sq. M,Month

Outdoor P8 LED Display BoardTechnical ParametersLED ParametersNo.ItemLuminous IntensityWavelength1Red LED600-800mcd620-630nm2Green LED1800-2000mcd520-525nm3Blue LED400-600mcd465-470nmModule Specifications1Pixel Pitch8mm2Pixel Configuration1R1G1B3Module Resolution32 x 16 pixels4Module Pixles512 pixels5Module Size256mm X 128mmCabinet Specifications1Cabinet Size(mm)(WXHXD)1024mm x 768mm x 165mm2Cabinet Resolution(dot)128 x 96 pixels3Module Quanity (pcs)24pcs4Cabinet Pixels12288 pixels5Pixel Density15625 pixels/m 26Cabinet MaterialStandard waterproof iron cabinetScreen ParametersLED display :1Display DimensionW6.144m x H3.072m, total 18.87m22Whole Screen ResolutionW768 x H384 pixel dots3Cabinet QuantityW6 x H4, total 24pcs4Screen Brightness≥6500cd/m25Screen Weight1100kg6Driving Method1/4 scan7H/V Visual Angle110º/50º8Best Viewing Distance8m - 150m9Max. Power Consumption1000W/m210Average Power Consumption600W/m211Gray Level8bits input, 4096 levels(2 12 )12Display Color16M13Frame Frequency≥60Hz14Refresh Frequency≥400Hz15Screen Life-span≥50,000hours16MTBF≥5,000 hours17Continuous Blind Spot RateNone18Blind Spot Rate<1/1000019Protective ScaleIP65(Front)/IP54(Rear)20Screen Plainness<±1mm21Power Supply ModeAC220±10%  50Hz/AC110±10%  60Hz22Environment Temperature & HumidityTemperature:-20 degrees~+60 degrees
Humidity:10%~90% RH23Control ModeSynchronous display with control PC by DVI24Control SystemDVI video card + full color control card + fiber system( optional)25Display ContentVideo, DVD, VCD, TV, picture, cartoon, graphics, texts.etc.26Brightness Adjustment32 levels adjustment by software27InterfaceStandard Ethernet28Transmission DistanceMulti mode fiber <500m, single mode fiber <30km,internet cable <100m
