• Model NO.：p10 outdoor
• Pixel Density：10000 dot , m²
• Scanning Mode：Static Scan
• Display Type：LED Video Display
• Application：Advertising
• Certification：CE, RoHS, UL, CCC, ETL, FCC
• LED Module Size：160mm*160mm
• LED Module Resolution：16*16 Dots
• Best Viewing Distance：10-200m
• LED Density of Pixel：10000dots,M2
• Colors：16777216
• Refresh Frequency：>=1920Hz
• Working Temperature：-25oc~65oc
• Horizontal Viewing Angle：120o
• Transport Package：Anti-Shaking Wooden Package&Air Freight Case
• Specification：P10 outdoor led display
• Trademark：Foxgolden
• Origin：Shenzhen, Guangdong, China
• HS Code：8528591090
• Production Capacity：5000sqm,Month

Basic Info.

Model NO. p10 outdoor Pixel Density 10000 dot / m² Scanning Mode Static Scan Display Type LED Video Display Application Advertising Certification CE, RoHS, UL, CCC, ETL, FCC LED Module Size 160mm*160mm LED Module Resolution 16*16 Dots Best Viewing Distance 10-200m LED Density of Pixel 10000dots/M2 Colors 16777216 Refresh Frequency >=1920Hz Working Temperature -25oc~65oc Horizontal Viewing Angle 120o Transport Package Anti-Shaking Wooden Package&Air Freight Case Specification P10 outdoor led display Trademark Foxgolden Origin Shenzhen, Guangdong, China HS Code 8528591090 Production Capacity 5000sqm/Month

Product Description

Hot Selling P10 Outdoor Full Color LED Billboard


1. UL, CE&RoHS&SGS2. Easy operation, installation
3. High brightness and clear Video
4. Warranty 5years
5. Good waterproof
6LED display manufacture
vv
Function and Technology Character
(1) Multiform file formats, such as VGA, Video, AVI, MOV, MPG, DAT, VOB and so on are comprehensive.
(2) Information source can be camera, video, VCD, DVD, LD, TV and so on.
(3) Clear picture without flicker and distortion.
(4) Brightness, contrast, saturation can be adjust by itself and manual.
(5) Show everything with your PC does synchronously or offline does asynchronously
(6) Super correcting technology for distortion.
(7) One interface for sound signal and two for video signal at least.
(8) Connected and controlled by PC via LAN and remote control.
(9) Multiform language editions, such as English, French, Germany, Greek, Russian and so on.
(10)Can be connected with PC and the website, and also can be controlled remotely via wireless controller




º Cº Cº CNumber	Item	P10
1	Pixel pitch	10mm
2	Size of  Module	160mm X 160 mm
3	Resolution of Module	16 X 16
4	Density of pixel	10000dots/m2
5	Pixel configuration	1R1G1B
6	Red wavelength	625± 2nm
7	Green wavelength	525± 2nm
8	Blue wavelength	470± 2nm
9	Colors	16777216
10	Best viewing distance	10-200m
11	Horizontal viewing angle	120°
12	Maximum power consumption	≤ 800W/m 2
13	Brightness	≥ 10000cd /m 2
14	Gray scale	16bits per color
15	Color temperature	6500k
16	Control method	Synchronization & Asynchronization
17	Driving method	constant scanning
18	Frame frequency	60Hz
19	Refresh frequency	≥ 1920Hz
20	Working voltage	AC220V/110V± 10%
21	IP grade	IP65(adjustable)
22	Working temperature	-25º C~65º C
23	MTBF	> 10000 hours
24	Life span	> 100, 000 hours
25	Defects rate.	≤ 0.00001(Led display line standard< 0.0001)
26	Computer operation system	Win XP/Vista/  Win 2000/WIN7ect.
27	Video signal	RF, S-Video, RGB, RGBHV, YUV, YC. ect

Payment terms:
30% deposit before production, 70% balance before shipping
-T/T:
-Paypal
-Western Union
-Escrow
Packing:
-Standard Export Carton with fully Polyfoam or Pearl Wool
-Flight case;
-Anti-shaking wooden case
Shipping:
LED module: 3 to 5 working days upon receiving deposit payment
LED display: 5 to 8 working days upon receiving deposit payment
After-Sales-Service:
-Lifetime with professional engineer support for free.
-Within 1 year, supply spare parts for free if the machine has quality problem

FAQ

Q1: When is the delivery time?
A1: we will accomplish manufacturing within 10-15 days after receiving the deposit.

Q2: What is the payment method?
A2: We support a variety of payment methods, the most common is the TT.

Q3: Can it play HD video?
A3: Yes, it can realize HD video function with Linsn controlling system.

Q4: What's the controlling system?
A4: Our standard controlling system for this model is Linsn, Novastar. Also support other controlling system, like Xixun,TF, Colorlight, etc.

Q5: How about the size of project?
A5: Please offer the size with "width by height" of project. We will offer the suitable solution for your project size. I will appreciate it if any drawing files about installation offered.

Q6: How about your service?
A6:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
6. Special service for big project, such as stadium, exhibitions, squares and so on.

 Features:

• Light Weigh and small structure
• Wide range of sizes
• Fast Installation

Software:

• Graphic Creation Software
• Support all graphic formats (images, animations, graphics, videos, texts)
• Optional Temperature and Humidity real time display
• Schedule or Automatic brightness control
• Scheduling message contents

Control:

• Messages can be controlled by PC control or online cloud message control

Cabinet:

• Durable and sturdy aluminum casting cabinet
• IP65 Waterproof



Outdoor LED signs provide your business with eye catching and attractive advertising solution that capture attention of your viewers.
Compare with traditional form of static or printed signs, electronic signs are capable to increase visibility of your business up to 900%
and increase your sales between 15 to 50%.


Shenzhen Foxgolden Technology Limited, is one of the most impressing Hi-tech enterprises in China. Since 2004,
we have been dedicating to the aim that making high quality products, and have been well integrated with R&D,
production, project, capital and marketing.

As a professional and market-oriented LED display manufacturer, FOXGOLDEN not only keeps improving on normal LED
display screen, enhances the product's cost-effective and overall market competitiveness, but also makes breakthrough
progresses on special usages. Our products, with high quality and competitive prices, spread worldwide and earn excellent
public reputation from both domestic and overseas market.
