Outdoor P4.81 P6.25 Full Color SMD LED Module (250X250mm)

PRT Optoelectronic Co., Ltd.
  • Tube Chip Color：Full Color
  • IP Rating：65
  • Pixel Pitch：4.81mm
  • Display Function：Video Display
  • Pixel Density：43264dots,Sq.M
  • Scanning Mode：1,13

Base Info

  • Model NO.：P4.81-outdoor
  • Display Type：LED Video Display
  • Certification：CE, RoHS, CCC, FCC
  • LED Style：SMD2727 Black
  • Module Size：250X250mm
  • Module Resolution：52X52dots
  • Brightness：5500CD,M2
  • Transport Package：Wooden Case
  • Specification：CE, FCC, Rohs
  • Trademark：PRT
  • Origin：Shenzhen China
  • HS Code：8528591090
  • Production Capacity：10000PCS,Month

Description

P4.81 SMD2727 outdoor full Color LED Screen SpecificationPixel pitch4.81mmPixel Configuration1R1G1BLED componentSMD2727 blackSize of module250mm*250mmResolution of module52x52Size of cabinet500x500mm/ 500mm x 1000mmResolution of cabinet128x128 dots or 128x256dotsMaterial of CabinetDie-casting Aluminum/Aluminum profileWeight of Cabinet6.8kgs/13KGSBrightness>5500cd/sq.mDensity43264dots/sq.mBest viewing angle140 /140Pixel Configuration1R1G1BBest viewing distance4-50MMaximum power consumption1100W/sq.mAverage power consumption600W/sq.mDriving method1/13 scanControl methodSynchronizationGray scale65536Colors256*256*256Color temperature3200-9300kUniformity97%Working voltageAC220V/110V±10%Working temperature-20ºC~+50ºC±10%Working humidity10% ~ 90%MTBF10,000 hoursFrame frequence50/60HzRefresh frequence>1920HzIP gradeIP65Life Span100,000 hoursData transafer methodRJ45Pratical standardCCC  TUV-CE  ETL etc.Effectivce Communication
Distance(without relay)Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M;
Single-mode optic fiber: 10KMAccepting signal with video processorPAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc.Systems operating platformWINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development
