• Model NO.：Indoor P6 LED Display
• System Operating Platform：Windows XP , Windows 7 , Windows 8 ,8.1 , 10
• Display Type：LED Video Display
• Application：Stage Performance, Advertising, Shopping Guide
• Certification：CE, RoHS, CCC, ISO9001 ISO14001 FCC001 ISO14001 FCC
• Product Name：P6 Indoor LED Display
• Driver IC：Mbi5124
• Brightness：1500CD,M2
• Grey Scale：65536 Degree
• Life Time：More 100,000 Hours (80%)
• Mtbf：More 50,000 Hours
• Operating Temperature：-30~-60t
• Humidity：10%-95%
• Color Temperature：6500K-9500K
• Refreshing Rate：1920Hz
• Transport Package：Wooden Case, Flight Case, and Carton
• Specification：192*192mm
• Trademark：hongking
• Origin：Shenzhen China
• HS Code：8528591090
• Production Capacity：50000 Sqm,Year

NO.:Product nameindoor P6 led display1Pixel Pitch(mm)6mm2Pixel configuration1R1G1B/SMD35283Pixel density27777dots/sqm4Brightness ≥1500cd/sqm5Module size(W*H)192mm×192mm6Module Resolution (W*H)32 dots x 32dots7Module weight600g8Cabinet size (W*H)960mm×960mm9Drive ICMBI5124 or ICN2038s10Drive mode1/16 scan11Viewing Angle(V/H)140 ºC12Grey Scale65536 degree13Life time>100,000 Hours(80%)14MTBF>50,000 Hours15Operating VoltageAC110V/220V±10%17Screen Power ConsumptionMax: 760w/sqm; Average:230w/sqm18Input Power Frequency50/60Hz19Operating temperature -30--60degree20Humidity10%-95%21Refresh Rate≥1920HZ22Control MethodSynchronized with computer monitor










Professional production:
Full Color LED Display,Indoor LED Display,Outdoor LED Display,Rental LED Display,Outdoor SMD LED Display,Outdoor DIP LED Display,Full Color LED Display Module,Single Color LED Display Module,Transparent LED Display,Advertising LED Screen

Company descripition:
HONGKINGLED is a publicly listed LED display manufacturer. Our facilities cover an area of 1000 square meters. Our company strives to deliver stunning LED solutions that can satisfy all customer requirements. Standardization and flexible production allow us to offer competitive prices for a wide range of high quality products. Our valued clients can enjoy the benefits of attentive service and prompt delivery. For the past 6 years, we have made steady progress.

Ingenuity and perseverance have firmly established us as pioneers in the LED display industry. Our company is dedicated to the research and development of LED related technologies. HONGKINGLED products are approved by CE, CCC, EMC and FC. We are fully certified by ISO standards.
