• Model NO.：STA
• Refresh Rate (Hz)：1920
• Module Size：500*125
• Cabinet Resolution：256*64
• Brightness (Nits)：4000-4500
• Transparency：70%
• Cabinet Size (mm)：1000*1000
• LED Lamp：ODM Lamp
• Specification：1000*1000
• Origin：China

Basic Info.

Model NO. STA Refresh Rate (Hz) 1920 Module Size 500*125 Cabinet Resolution 256*64 Brightness (Nits) 4000-4500 Transparency 70% Cabinet Size (mm) 1000*1000 LED Lamp ODM Lamp Specification 1000*1000 Origin China

Product Description

STA Series Features
As an innovative transparent display, STA series uses an extremely narrow bezel design to reduce the weight of the screen and the blocking of light. It has become the best choice for the current stage, exhibition, commercial display and glass walkway.

Lightweight
The LED transparent screen with hollow strip design is more flexible and approximately 3x lighter than the non-transparent LED display structure.
High Protection,Front and Back Maintenance

Easy Installation
Frame design can be used for indoor and outdoor protection level support both front and back maintenance.
Quick lock design, reducing installation steps. Apply large size die-casting aluminum narrow frame to make the screen more stable
Rapid Dynamic Display
LED has nanosecond response time, its alternating time of lighting and extinguishing is very short, and there is no afterglow effect of fluorescent display technology, so it can respond to image changes quickly and has high dynamic definition. In particular, it has great inherent advantages for the high demand for dynamic effect restoration. The imaging mode of LED self illumination does not require response time, and there is no lag even in the performance of dynamic pictures. The dynamic definition is naturally higher, which is in line with the psychological perception of human eyes on the impact of motion.

Broadcast Level Gray Processing
Gray scale is the so-called color scale or gray scale, which refers to the degree of brightness and the number of layers of any color from dark to light; The LED transparent display screen achieves 16bit gray performance, and the gray performance of the display screen is still complete under low brightness; The higher the gray level, the higher the level and brightness of the picture, which can show more image details without information loss.
The color difference of low gray level is obvious
High gray level, smoother color transition

Accurate Color Management System
The precise color management system is adopted. After the video is decoded by the LED control system, the secondary filter display algorithm is added to correct the color of each LED on the display point by point.
Highly Transparent

Highly Stable

Remote and On-site Video Upload
Using remote upload control through our intelligent management platform allows users to easily control single or multiple displays simultaneously on assigned time.

Industry Leading Pixel Pitch 1.9mm
Industry's first pixel pitch 1 . 9mm was developed by Milestrong. Perfect display of high-definition videos.
The width of each LED light bar is between 1.56-4mm, and Extremely narrow border helps transparency up to 70%.

Outdoor High Protection Grade
The module design of the cabinet is easy to assemble, install and maintain. The module can be replaced separately.

Thickness
The thickness of the light board is 2-3mm, and the minimum width of the power box is 50mm.

Customized
The flexible frame supports curved installation, and a more suitable installation angle can be customized according to the location.
The module adopts advanced glue filling technology and waterproof rubber ring to achieve perfect waterproof, dustproof and shockproof. It can meet a variety of occasions inside and outside the user and achieve militar grade IP65 full protection.
